详细描述:
英国珀金斯Perkins柴油发动机2806A-E18TAG1A原装进口零配件 Buildlist: JGAF5004 序号 零件名称 零件号 数量(一车付) 1 Fuel Filter CH10931 1 2 Pre-Fule Filter CH10930 1 3 Oil Filter CH10929 1 4 Air Filter SEV551F/4 1 5 ALTERNATOR BELT CH11037 1 6 FAN BELT CH11186 1 7 SEAL - ROCKER BOX COVER CH11353 1 8 GASKET - CYLINDER HEAD KRP1529 1 9 THERMOSTAT CH11620 2 10 SEAL - FRONT END OIL CH11379 1 11 SEAL - REAR END OIL CH11304 1 12 Fuel Filter CH10931 1 13 Pre-Fule Filter CH10930 1 14 Oil Filter CH10929 1 15 ALTERNATOR BELT CH11037 1 16 FAN BELT CH11186 1 17 Air Filter SEV551F/4 1 18 SEAL - ROCKER BOX COVER CH11353 1 19 GASKET - CYLINDER HEAD KRP1529 1 20 PISTON RING KIT KRP3021 6 21 INTAKE VALVE CH11021 12 22 EXHAUST VALVE CH11022 12 23 INJECTOR CH12071 6 24 THERMOSTAT CH11620 2 25 TOP GASKET KIT KRP1656 1 26 BOTTOM GASKET KIT KRP1657 1 27 Fuel Filter CH10931 1 28 Pre-Fule Filter CH10930 1 29 Oil Filter CH10929 1 30 FAN BELT CH11186 1 31 ALTERNATOR BELT CH11037 1 32 Air Filter SEV551F/4 1 33 THERMOSTAT CH11620 2 34 VALVE SEAT INSERT CH10731 12 35 VALVE SEAT INSERT CH10732 12 36 SEAL - VALVE STEM CH11486 24 37 VALVE GUIDE CH10724 24 38 EXHAUST VALVE CH11022 12 39 INTAKE VALVE CH11021 12 40 VALVE COLLET CH10019 48 41 VALVE SPRING OUTER CH11487 24 42 VALVE SPRING INNER CH11489 24 43 SEAT CH10715 24 44 BIG END BEARING KIT KRP3022 1 45 PISTON KIT KRP3026 6 46 PISTON RING KIT KRP3021 6 47 CYLINDER LINER CH12742 6 48 BAND CH10673 6 49 SEAL - O RING CH11654 6 50 SEAL - O RING CH11655 6 51 SEAL - O RING CH10656 6 52 MAIN BEARING KIT KRP3122 1 53 THRUST WASHER KIT KRP3206 1 54 STARTER MOTOR CH11441 1 55 WATER PUMP KRP1715 1 56 ALTERNATOR CH11087 1 57 INJECTOR R/CH11945 6 58 TURBOCHARGER CH11607 1 59 GASKET - TURBOCHARGER CH11761 1 60 GASKET - CYLINDER HEAD KRP1529 1 61 SEAL - ROCKER BOX COVER CH11353 1 62 SEAL - FRONT END OIL CH11379 1 63 SEAL - REAR END OIL CH11304 1 64 SEAL - SUMP CH12739 1 65 PRIMING PUMP CH10439 1 66 LIFT PUMP KRP1679 1 67 OIL PUMP CH10860 1 68 TEMPERATURE SENSOR KRP1687 2 69 AIR PRESSURE SENSOR KIT KRP1692 1 70 AIR PRESSURE SENSOR KIT KRP1693 1 71 OIL PRESSURE SENSOR KIT KRP1699 1 72 TEMPERATURE SENSOR KRP1688 1 73 SPEED SENSOR KRP1700 1 74 SPEED SENSOR KRP1705 1 75 CRANKSHAFT ASSEMBLY CH11521 1 76 CAMSHAFT CH11520 1 英国珀金斯Perkins柴油发动机2806C-E16TAG2原装进口零配件 Buildlist: HGB061127U5571L 序号 零件名称 零件号 数量(一车付) 1 Fuel Filter CH10931 1 2 Pre-Fule Filter CH10930 1 3 Oil Filter CH10929 1 4 Air Filter SEV551F/4 1 5 ALTERNATOR BELT CH11037 1 6 FAN BELT CH11023 1 7 SEAL - ROCKER BOX COVER CH11353 1 8 GASKET - CYLINDER HEAD KRP1529 1 9 THERMOSTAT CH11620 2 10 SEAL - FRONT END OIL CH11379 1 11 SEAL - REAR END OIL CH11304 1 12 Fuel Filter CH10931 1 13 Pre-Fule Filter CH10930 1 14 Oil Filter CH10929 1 15 ALTERNATOR BELT CH11037 1 16 FAN BELT CH11023 1 17 Air Filter SEV551F/4 1 18 SEAL - ROCKER BOX COVER CH11353 1 19 GASKET - CYLINDER HEAD KRP1529 1 20 PISTON RING KIT KRP1528 6 21 INTAKE VALVE CH11021 12 22 EXHAUST VALVE CH11022 12 , 23 INJECTOR P/CH10948 6 24 THERMOSTAT CH11620 2 25 TOP GASKET KIT KRP1546 1 26 BOTTOM GASKET KIT KRP1547 1 27 Fuel Filter CH10931 1 28 Pre-Fule Filter CH10930 1 29 Oil Filter CH10929 1 30 FAN BELT CH11023 1 31 ALTERNATOR BELT CH11037 1 32 Air Filter SEV551F/4 1 33 THERMOSTAT CH11620 2 34 VALVE SEAT INSERT CH10731 12 35 VALVE SEAT INSERT CH10732 12 36 SEAL - VALVE STEM CH11486 24 37 VALVE GUIDE CH10724 24 38 EXHAUST VALVE CH11022 12 39 INTAKE VALVE CH11021 12 40 VALVE COLLET CH10019 48 41 VALVE SPRING OUTER CH11487 24 42 VALVE SPRING INNER CH11489 24 43 SEAT CH10715 24 44 BIG END BEARING KIT KRP3012 1 45 PISTON KIT KRP1527 6 46 PISTON RING KIT KRP1528 6 47 CYLINDER LINER CH11205 6 48 BAND CH10673 6 49 SEAL - O RING CH10675 6 50 SEAL - O RING CH10674 6 51 SEAL - O RING CH10677 6 52 MAIN BEARING KIT KRP3116 1 53 THRUST WASHER KIT KRP3206 1 54 STARTER MOTOR CH12807 1 55 WATER PUMP KRP1553 1 56 ALTERNATOR CH11087 1 57 INJECTOR P/CH10948 6 58 TURBOCHARGER P/CH10899 1 59 GASKET - CYLINDER HEAD KRP1529 1 60 SEAL - ROCKER BOX COVER CH11353 1 61 SEAL - FRONT END OIL CH11379 1 62 SEAL - REAR END OIL CH11304 1 63 PRIMING PUMP CH10439 1 64 LIFT PUMP KRP1679 1 65 OIL PUMP CH10860 1 66 TEMPERATURE SENSOR CV18338/5 2 67 AIR PRESSURE SENSOR KIT KRP1560 1 68 AIR TEMPERATURE SENSOR KIT KRP1556 1 69 OIL PRESSURE SENSOR KIT KRP1559 1 70 OIL PRESSURE SENSOR KIT CV18339/2 1 71 AIR PRESSURE SENSOR KIT KRP1558 1 72 TEMPERATURE SENSOR KRP1557 1 73 SPEED SENSOR KRP1561 1 74 SPEED SENSOR KRP1551 1 75 CRANKSHAFT ASSEMBLY CH10651 1 76 CAMSHAFT CH10964 1 77 TOP GASKET KIT KRP1546 1 78 BOTTOM GASKET KIT KRP1547 1
日兴动力科技建立了一套完整的英国珀金斯Perkins零配件供应体系,全天候快速供应,从而能够保证您的Perkins机器正常运转。珀金斯Perkins的备用零件的库存齐全,全部采用电脑化管理,随时满足您的零件需要,纯正的珀金斯Perkins配件是您最佳的选择,因为您所得到的是延长珀金斯Perkins机器寿命的最佳保证。
注意:网页中公布的Perkins发动机配件号与图片仅为参考,因 英国珀金斯Perkins柴油发动机/零配件型号与技术参数太多,没能全部展示,如有零配件与维修技术方面的需求,请与本司的在线客服人员沟通与交流,希望我们能够帮您节约更多等待备件到达的时间和维修技术方面的困难。
